F016A/OX03C10 2.5MP

The F016A FalconView® is a high resolution automotive LVDS camera with high dynamic range, LFM and superior image performance. This camera includes FalconView® optics lens, 2.5M CMOS image sensor with low voltage differential signaling encode chip to cover variety ADAS applications.

Features

• 2.5M (1920*1280) resolution, 3um pixel size, 1/2.6-inch image sensor.

• Frame rate:

  30fps at 1920*1280 (default).

  60fps at 1920*1280 (max).

• Support linear and high dynamic range (HDR) mode.

• Support for LED flicker mitigation (LFM) function.

• Support external synchronizing function for multi-camera system.

• 9V~16V wide operation voltage input (recommend 12V).

• Power consumption to 1.1W (default output 1920*1280@30 fps).

• Support 12,14,16,20,24-bit RGGB raw output by LVDS interface.

• Automotive grade design and construction.

• FAKRA Z type cable connector.

Application

• Autonomous driving

• Automotive ADAS

• Mirror Replacement

• High dynamic range imaging

• Others viewing applications

Platform Support

NXP  i.MX 9 Processors

•  i.MX95: i.MX 95 Applications Processor Family: High-Performance, Safety Enabled Platform with eIQ® Neutron NPU

NXP  i.MX 8 Processors

•  i.MX8MPLUS: i.MX 8M Plus – Arm® Cortex®-A53, Machine Learning, Vision, Multimedia and Industrial IoT
