EPCIE003
EPCIE003 is a high-performance PCIe Data Grabber with advanced technology and user-friendly design. It collects and transmits 8-way video data efficiently and offers AI extensions, image processing, and secure license management. Boost your projects with EPCIE003!
Features
• Serdes to PCIe conversion
• Linux, Windows OS enabled (Linux default)
• Up to 8x channel Serdes camera (GMSL2/3, FPD-Link4, default GMSL2)
• PCIe standard: PCIe GEN3.0x4, 8GT/S
• 4GB DDR4 DRAM memory
• Support synchronization
• ISP (optional)
• Superfast data transmission rate
• 8 x 8MP@30fps camera (max)
• Support Micro HDMI display
• Virtual camera data transmission
• 100base-T1 Automotive Ethernet
Applications
• Serdes to PCIe Data Grabber
• AI machine learning simulation
• Automotive/ Industrial/ Robotics
